Introduzzjoni
Il-kumpanija tagħna tispeċjalizza fil-produzzjoni tal-magna tal-loader, il-kwalità tal-prodott tagħna hija ta 'min joqgħod fuqha.Jiangsu Sida Power Makkinarju hija kbira - kumpanija ta' grupp ta 'skala modernizzata li tintegra l-industrija tal-magna diesel, l-industrija tat-tagħmir tal-loġistika u l-fornitur tal-karozzi tal-elettriku.
Oriġinali: Jiangsu, Dettall taċ-ChinaProduct
Certification: IATF16949 etc.
Prezz: Negozjabbli
Terminu tal-ħlas: T / T, L / C
Data tal-kunsinna: Negozjabbli
Ippakkjar: pakkett standard għall-esportazzjoni
Suq: Lvant Nofsani / Afrika / Asja / Amerika t'Isfel / Ewropa / Amerika ta 'Fuq
Warranty: 1 year or warranty exclusive agreement
MOQ: 1 set
Speċifikazzjonijiet Tekniċi
| Engine & nbsp; Model | SD485 | SD 490 | SD 493 | SD 490Z | SD 493Z | SD4102 | SD4102Z | SD4102ZL |
| Aspirazzjoni | Naturali | Turbocharged | Naturali | Turbocharged | Turbo + Intercooling | |||
| Kombustjoni | Direct & nbsp; injection | |||||||
| Gvernatur | Mekkanika | |||||||
| Numru taċ-Ċilindru | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Forom × Stroke (mm) | 85x100 | 90x100 | 93x102 | 90x100 | 93x102 | 102x115 | 102x115 | 102x115 |
| Spostament (L) | 2.27 | 2.55 | 2.77 | 2.55 | 2.77 | 3.76 | 3.76 | 3.76 |
| Proporzjon ta 'kompressjoni | 19.1:1 | 17.5:1 | ||||||
| Qawwa nominali (KW) | 17/20/24 | 23/27/35 | 25/30/42 | 30/36/54 | 36/43/66 | 34/40/66 | 46/55/85 | 52/62/90 |
| r / min | 1500/1800/3000 | |||||||
| Veloċità massima wieqfa（r / min) | ≤1575 | ≤1575 | ≤1575 | ≤1575 | ≤1575 | ≤1575 | ≤1575 | ≤1575 |
| Tagħbija minima ta '- b'veloċità stabbli（r / min) | 800～850 | |||||||
| Fuel & nbsp; consumption（g / kW.h） | 245 | 245 | 245 | 240 | 230 | 245 | 245 | 245 |
| Sistema ta 'tkessiħ | water & nbsp; cooling | |||||||
| Sistema ta 'lubrikazzjoni | Combined & nbsp; Pressure & amp; Splashing | |||||||
| Daqs (mm) | 735x585x637 | 825x623x788 | ||||||
| Sekwenza tax-xogħol taċ-ċilindru | 1-3-4-2 | |||||||
| Intake pipe & nbsp; diameter mm | ∅60 | ∅64 | ||||||
| Volum taż-Żejt L | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 |
| Maximum oil & nbsp; temperature℃ | 120 | 120 | 120 | 120 | 120 | 120 | 120 | 120 |
| Tip tat-Tluq | 12V - DC | |||||||
| Flaywell - SAE | SAE 4 - 7, 5 0010010 # 39; & # 39; | SAE 3-10 / SAE 3 - 11, 5 0010010 # 39; & # 39; | ||||||
Il-karatteristiċi ewlenin tal-prodott
1. Imla r-rekwiżiti tal-qawwa tal-makkinarju tal-kostruzzjoni fit-taqsima 30-140 horsepower.
2.According to the characteristics of construction machinery, low speed and high torque, strong idle load capacity, low speed torque reserve as high as 30%.
3.The stroke of SDDW series products is increased from 100 to 102 mm, 15% higher than the same kind of power, and the power is stronger.
4.Using electronic control VE pump technology, the quality is stable, the noise is low, the market quantity is large, the maintenance cost of parts is low, the user use cost is recovered quickly, the economy is comfortable, and the comprehensive fuel consumption is reduced by more than 5% compared with the same period last year.
5.The company has 450 engine service organizations, 150 accessories center library, distribution point, relying on ecommerce platform to fully meet the needs of user service maintenance.
